Solar Pod Solar Heating Kit For Swimming Pools
The Plastica Solar Pod is designed as an additional source of heating for your swimming pool. Suitable for above ground or in-ground pools.
ZERO HEATING COSTS- harness the energy from the sun and transfer it into your pool water using "heat trap" glasshouse effect technology.
UNIQUE DESIGN- the compact contemporary design makes the Solar Pod an attractive addition to your garden.
FOR ALL ABOVE GROUND POOLS- one pod is suitable for pools up to 4500 litres. For larger pools simply connect several units in series.
SIMPLE TO INSTALL- requires only a Philips screwdriver and silicone lubricant.
VIRTUALLY MAINTENANCE FREE- simply wipe the Solar Pods over with a non-abrasive cloth and store in a frost free location for the winter season.

To download Solar Pod brochure click here
FEATURES:
- For above ground and in-ground pools
- Compact size of 580mm x 580mm
- Coil made of strong polypropylene
- Dome made of stong transparent polycarbonate
- Easy connection
- Connect multiple units for larger pools
- Works with existing pool pump*
- Minimal tools required (Philips screwdriver and silicone lubricant)
- Tilts to achieve best angle for sun
- No servicing required (other than winterising)
NOTE:- The pump supplied with your pool may not deliver sufficient flow-rate to circulate around the pool. For long pipe runs and for where the panels are elevated onto roofs etc this will almost certainly be the case. In these instances a booster pump or larger pump may be required.
Each kit includes:
- Main base with stand
- 1.25’’ to 1.5’’ hose reducer
- Collared tube adaptor
- Hose clamps
- Thick connector gasket
- 1m hose
- Side hose connector x2
- 380mm hose
- Clear dome
- Solar protection cover
The Plastica Solar Pod is also suitable for use with Intex Swimming Pools via the use of additional 1.25" hose.
QUANTITY REQUIRED:
|
Description
|
Width (m)
|
Length (m)
|
Water Depth (m)
|
Est. Volume (litres)
|
Solar Pods
|
|
Round
|
2.4
|
2.4
|
0.75
|
3400
|
1
|
|
Round
|
2.4
|
2.4
|
0.90
|
4100
|
1
|
|
Round
|
3.0
|
3.0
|
0.75
|
5300
|
2
|
|
Round
|
3.0
|
3.0
|
1
|
7100
|
2
|
|
Round
|
4.0
|
4.0
|
1
|
12600
|
3
|
|
Round
|
4.0
|
4.0
|
1.10
|
13800
|
4
|
|
Round
|
6.0
|
6.0
|
1
|
28300
|
7
|
|
Rectangular
|
3.0
|
6.0
|
0.80
|
14400
|
4
|
|
Rectangular
|
4.0
|
8.0
|
0.80
|
25600
|
6
|
|
Oval or
Octagonal
|
4.0
|
4.0
|
1.10
|
13800
|
4
|
|
Oval or
Octagonal
|
5.0
|
5.0
|
1.10
|
21600
|
5
|
|
Oval or
Octagonal
|
6.0
|
6.0
|
1.10
|
31100
|
7
|
|
Oval or
Octagonal
|
4.0
|
6.0
|
1.10
|
21800
|
5
|
|
Oval or
Octagonal
|
4.0
|
7.0
|
1.10
|
25800
|
6
|
